Frigidaire Gallery Ice Maker Not Working – Fix It Now
1. Ice Maker Is Turned Off or in Test Mode
The Gallery ice maker has an on/off switch or a bail arm; if it was accidentally flipped during cleaning or restocking, the unit simply stops making ice.
- Open the freezer and locate the ice maker on/off switch (usually a rocker switch on the side of the unit) or the wire bail arm.
- Confirm the switch is in the ON position, or lower the bail arm so it sits below the ice bucket rim.
- Wait 24 hours for a new cycle to complete before concluding the problem persists.
2. Freezer Temperature Too Warm
Frigidaire requires the freezer to be at or below 0 °F (−18 °C) for the ice maker to run reliably; temperatures above 10 °F will pause production.
- Place a freezer thermometer on the middle shelf and wait 4–6 hours for an accurate reading.
- Navigate to the control panel and set the freezer to 0 °F if it is set warmer.
- Check that the condenser coils (behind or underneath the refrigerator) are not coated in dust — dirty coils raise freezer temps. Clean with a coil brush if needed.
- If the freezer still won’t reach 0 °F, the evaporator fan or condenser fan may be failing (see a technician).
3. Water Supply Issue
No water reaching the ice maker is one of the most common reasons a frigidaire gallery ice maker not working complaint appears — the shut-off valve, supply line, or water inlet valve is usually to blame.
- Locate the water shut-off valve (typically under the sink or behind the refrigerator) and confirm it is fully open.
- Inspect the water supply line for kinks, pinches, or freezing near the back of the refrigerator.
- Disconnect the supply line at the refrigerator and hold it over a bucket — turn the valve on briefly to confirm good flow pressure (you need at least 20 psi).
- If pressure is fine but no water enters the ice maker, the water inlet valve is likely clogged or electrically failed. Replace it.
Check price
4. Frozen or Clogged Fill Tube
The small plastic fill tube that carries water into the ice mold can freeze solid, blocking water delivery even when the valve is working perfectly.
- Unplug the refrigerator for safety.
- Locate the fill tube at the back of the ice maker compartment — it is usually white or clear plastic about ½ inch in diameter.
- Use a hair dryer on a low setting or a turkey baster filled with warm water to gently thaw the tube. Do not use an open flame.
- Once thawed, plug the refrigerator back in and run a test cycle. If the tube refreezes repeatedly, the water inlet valve may be leaking slightly and dripping water that refreezes — replace the valve.
Check price
5. Faulty Ice Maker Module or Mold Thermostat
The ice maker module (the motorized head assembly) controls the harvest cycle; a failed mold thermostat inside it can prevent the unit from ever triggering a harvest.
- Press the Test button on the ice maker module (a small recessed button on the front or side of the head unit) and hold it for 3 seconds. You should hear the motor begin to turn and see the ejector blades rotate within a minute.
- If nothing happens and power is confirmed at the unit, the module itself is faulty.
- Unplug the refrigerator, remove the two mounting screws holding the module to the ice maker, disconnect the wiring harness, and swap in a new module.
Check price
6. Frigidaire Gallery Ice Maker Not Working Due to a Bad Door Switch or Ice Level Sensor
The refrigerator door switch cuts power to the ice maker and dispenser when the freezer door is open; a stuck or broken switch can leave the ice maker permanently disabled.
- Open the freezer door and manually press the door switch plunger — you should hear the interior light click off.
- Use a multimeter set to continuity mode: probes on the two switch terminals should show continuity when the button is pressed and no continuity when released (or vice versa depending on switch type). No change indicates a failed switch.
- Also inspect the ice level optical sensor (two small emitter/receiver eyes on the sides of the ice bucket area). Wipe them clean with a dry cloth — ice dust or residue can block the beam and trick the refrigerator into thinking the bin is full.
- Replace the door switch or optical sensor board as needed.
Check price
Check price
For model-specific wiring diagrams and the official reset procedure, visit the Frigidaire official support page.
Frequently asked questions
How do I reset my Frigidaire Gallery ice maker?
Press and hold the Test button on the ice maker module for about 3 seconds until you hear the motor activate. The unit will run through a complete harvest cycle. If water fills the mold and ice ejects normally, the ice maker has reset successfully. Allow 24 hours for full production to resume.
How long does it take for a Frigidaire Gallery ice maker to start making ice after being reset?
After a reset or initial startup, expect your first batch in roughly 6–12 hours. Full production capacity (roughly 3–7 lbs per day depending on model) is typically reached within 24 hours once the freezer is at 0 °F.
Why is my Frigidaire Gallery ice maker making small or hollow ice cubes?
Small or hollow cubes almost always indicate low water pressure or a partially blocked water inlet valve screen. Confirm household water pressure is at least 20 psi at the refrigerator connection, and remove and rinse the inlet valve’s mesh filter screen to clear any sediment buildup.
Is there a filter that could cause the ice maker to stop working?
Yes. A severely clogged water filter restricts flow enough to prevent the ice maker from filling. Frigidaire recommends replacing the refrigerator water filter every 6 months. Try bypassing the filter temporarily with a bypass plug (available from Frigidaire) — if ice production resumes, replace the filter.
